Want a powerful 1GHz AM3358 powered Linux single board that's ultra-tiny and open-source? PocketBeagle offers a wealth of computer power in a small footprint (pawprint?). This board is just like the BeagleBone Black but small enough to fit in your wallet. It has a fully-integrated chip that combines the processor and RAM all on one chip, so it's super small. Despite the compact shape, there are 72 total breakout pads, a microSD card slot for your filesystem and OS, and a native USB connection
Compared to other single board Linux computers, what differentiates the BeagleBone is that it has multiple I2C, SPI and UART peripherals (many boards only have one of each), built in hardware PWMs, analog inputs, and two separate 200MHz microcontroller system called the PRU that can handle real-time tasks like displaying to RGB matrix displays or NeoPixels.
It's not too much larger than our Feathers, but comes with 72 expansion pin headers, high-speed USB, 8 analog pins, 44 digital I/Os, and plenty of digital interface peripherals.
You can also add a USB host connection by wiring a USB A socket to the broken out USB host connections labeled VI, D+, D-, ID and GND. Then plug in any USB Ethernet, Bluetooth, and Wi-Fi device with available Linux drivers.
Technical Details
Processor: Octavo Systems OSD3358 1GHz ARM® Cortex-A8
- 512MB DDR3 RAM integrated
- Integrated power management
- 2×32-bit 200-MHz programmable real-time units (PRUs)
- ARM Cortex-M3
Key Features
- Low cost Linux computer with a lot of GPIO
- Opportunity to learn many programming aspects from educators on-line
- Openness and flexibility tear-down limits on your imagination
Technical Specifications
- Based on new Octavo Systems OSD3358-SM 21mm x 21mm system-in-package that includes 512MB DDR3 RAM, 1-GHz ARM Cortex-A8 CPU, 2x 200-MHz PRUs, ARM Cortex-M3, 3D accelerator, power/battery management and EEPROM
- 72 expansion pin headers with power and battery I/Os, high-speed USB, 8 analog inputs, 44 digital I/Os and numerous digital interface peripherals
- microUSB host/client and microSD connectors
Product Dimensions: 55.0mm x 35.0mm x 5.0mm / 2.2" x 1.4" x 0.2"
Product Weight: 10.7g / 0.4oz
- Reviews
- Questions
Australiavery sad
mediocreit takes days to do things a esp32 does in seconds or real linux does instantlybasic python gpio is not installedinternet never works for me on usb so the product was not usable till I made a usb adapter.I only program in python now on my phone, computer or esp32. I use to do this for a living in many languages and money would not drag me backwards to c programmingand this ****** toy wants me to program neopixels in c. badly. the software interface is good. the speed runs circles around the pi zerow.as a toy it is ok. but I would never use it in a project
Pakronics®
Thank you for your valuable input.
