Note: This is a white-label version with no branding. If you’re looking for the branded SenseCAP version, please check:
- SenseCAP T1000-A
- SenseCAP T1000-B
- Seamless indoor and outdoor positioning
T1000 effectively employs BLE and Wi-Fi for pinpoint indoor positioning and utilizes GNSS technologies, including GPS, Beidou, Galileo, and GLONASS for precise outdoor tracking.
- Months of battery after a single magnetic charge
With magnetic charge design to enhance water resistance. (PS: Battery life depends on upload interval, work mode, etc., please refer to datasheet)
- Offline data storage up to 1000 records
When temporarily disconnected from the LoRaWAN network, the tracker can store up to 1000 location records locally. All data will be automatically uploaded once the connection is restored.
- White-label ready for rapid integration
Delivered with a clean, unbranded appearance to support fast OEM deployment—perfect for businesses looking to add their own branding, customize protocols, or scale product lines without starting from scratch.
General Parameters | |
Backhaul | LoRaWAN® (v1.0.4 Class A) |
Bluetooth | Bluetooth v5.1, setting via App |
LoRaWAN Channel Plan | IN865/EU868/US915/AU915/AS923/ KR920/RU864 |
Temperature | Range: -20 to 60℃ ; Accuracy: ± 1℃ Resolution: 0.1℃ |
Light | 0 to 100% (0 is dark, 100% is brightest ) |
3-Axis Accelerometer | 3-Axis Accelerometer to detect movement |
LED and Buzzer | 1*LED and 1* buzzer to indicate status |
Button | 1*Button to operate and trigger events(SOS) |
Antenna | Internal (GNSS/LoRa/Wi-Fi/BLE) |
Communication Distance | 2 to 5km (depending on gateway antenna, installation, and environments) |
IP Rating | IP65 |
Dimensions | 85 x 55 x 6.5 mm |
Device Weight | 32g |
Operating Temperature | -20℃ to +60℃ |
Operating Humidity | 5% - 95% (No condensation) |
Certification | CE /FCC /TELEC /RoHS /REACH |
Location | |
GNSS Constellation | GPS/GLONASS/Galileo/ BeiDou/QZSS |
GNSS Sensitivity | -145dBm cold start / -160 dBm Tracking |
GNSS Location Accuracy | ~1m CEP, GPS, -130dBm |
Wi-Fi Positioning | Passive scanning, uploads the scanned 4 MAC addresses |
Bluetooth Positioning | uploads the scanned 3 best signal MAC addresses of Beacon |
Data Cache | Cache 1000 data when there is no LoRaWAN network |
Battery | |
Battey Capacity | Rechargeable lithium battery, 700mAh |
*Battery Life Estimates | 4 months on a single charge(uplink every 1 hour, only GNSS data) |
Battery Life Monitoring | Periodic uplink battery level |
Charge Cable (Adapter not included) | USB magnetic charging cable, 1 meter |
Power Input Voltage | 4.7 to 5.5V DC |
Charging Temperature | 0 to +45℃ (Beyond the temperature range, the charge will be limited, and the LED will blink quickly) |
Software | |
Work Mode | Standby: only heartbeat uplink; Periodic: upload location in intervals; Event: modify the interval by temperature, light and motion(start, end, shock, motionless timeout); |
Data Storage | Over 1000 location data records store on the device when there is no LoRaWAN® coverage |
App | Configuration via Bluetooth App |
- Tracker T1000 Datasheet
- Tracker T1000-A/B User Guide
- Tracker Battery Life Calculator
- SenseCAP T1000 3D Printing Charging Station Files by Alberto Gorni
- IP65 Test Report
- CE Certification
- FCC Certification
- TELEC Certification
- RoHS Certification
Card Tracker White Label T1000 | x1 |
USB Cable (Adapter not included) | x1 |
| HSCODE | 9031809090 |
| USHSCODE | 9031808085 |
| UPC | |
| EUHSCODE | 9013101000 |
| COO | CHINA |
