- High-Performance Dual-Core Processing
Powered by the AM6254 SoC, features quad ARM Cortex-A53 cores up to 1.4 GHz, with 512MB LPDDR4 SDRAM running at 3200 MHz and a microSD card slot for storage. - Advanced Real-Time Control
A single-core ARM Cortex-M4F MCU running at up to 400 MHz and a dual-core Programmable Real-Time Unit Subsystem (PRUSS) at 333 MHz enable precise real-time control and automation, making it ideal for time-sensitive applications. - Pocket-Size with Rich Peripherals
55 x 35 mm compact size and 72 expansion pin headers with power and battery I/Os, high-speed USB, 8 analog inputs, 52 digital I/Os, and numerous digital interface peripherals. One dedicated MSPM0L1105 Arm Cortex-M0+ MCU for 12-bit ADC. - Power Management System
The TPS6521903 PMIC combines system-level power management optimization with BQ21040 to support intelligent charging of single-cell Li-Ion and Li-Polymer batteries, enabling seamless power switching and facilitating space-limited portable applications.
Parameters | Description |
CPU | TI AM6254 - Quad ARM Cortex-A53 cores@1.4 GHz |
TI AM6254 - ARM Cortex-M4F core@400 MHz | |
GPU | Supports at least 2 composition layers Supports up to 2048x1080 @60fps Supports ARGB32, RGB565 and YUV formats |
SDRAM Memory | 512MB DDR4 3200 MHz |
PMIC | TPS6521903 |
Indicators | 1 x Power 1 x Battery charging 4 x User Controllable LEDs |
Interfaces | 72 × GPIO |
Buttons | 1 User/Boot Button 1 Power button |
Debug Support | 3 pin 3.3V JST-SH 1.00mm UART debug port (RPI debug probe compatible) |
10-pin JTAG TAG-CONNECT footprint | |
Power Source | USB C or Cape Header VIN (5V @ 1A) |
SD/MMC Connector | microSD (1.8/3.3V) |
Dimensions | 55 x 35 mm |
- Onboard
- PinOut
- Industrial automation
- Robotics
- Internet of Things (IoT)
- Embedded teaching
- Home automation
- Edge computing
BeagleBoard PocketBeagle 2 Documentation
BeagleBoard PocketBeagle 2 | x1 |
Getting Started Guide | x1 |
| HSCODE | 8517180050 |
| USHSCODE | 8543708800 |
| UPC | 841454123484 |
| EUHSCODE | 8543709099 |
| COO | CHINA |
