Arduino Nano Every with headers

4 reviews
Save 5% Regular price A$29.11
Price:
Sale price A$27.65   Inc. GST
SKU:
ARD-ABX00033
27 units Ships in 24 hours
50 units Ships in 10 to 15 days

The Arduino Nano Every is a suitable board for many projects which requires a small and easy to handle microcontroller board. The cheaper price and smaller size make the Nano Every preferable for the wearable inventions, low budget robotics project, electronics musical instruments and at time it is also used to control the smaller parts in the larger project.

The Arduino Nano Every is an evolution of the traditional Arduino Nano board but features a lot more powerful processor, the ATMega4809. This will allow you to make larger programs than with the Arduino Uno (it has 50% more program memory), and with a lot more variables (the RAM is 200% bigger).

Here is the Pinout Diagram:

Arduino Nano Every with headers pin diagram

Resources used for programming:


The Arduino Nano Every is based on the ATMega4809 microcontroller.


Technical Specifications of Arduino Nano Every:

MicrocontrollerATMega4809 (datasheet)
Operating Voltage5V
VIN min-MAX7-21V
DC Current per I/O Pin20 mA
DC Current for 3.3V Pin50 mA
Clock Speed20MHz
CPU Flash Memory48KB (ATMega4809)
SRAM6KB (ATMega4809)
EEPROM256byte (ATMega4809)
PWM Pins5 (D3, D5, D6, D9, D10)
UART1
SPI1
I2C1
Analog Input Pins8 (ADC 10 bit)
Analog Output PinsOnly through PWM (no DAC)
External Interruptsall digital pins
LED_BUILTIN13
USBUses the ATSAMD11D14A (datasheet)
Length45 mm
Width18 mm
Weight5 gr (with headers)
Customer Reviews
4.0 Based on 4 Reviews
5 ★
75%
3
4 ★
0%
0
3 ★
0%
0
2 ★
0%
0
1 ★
25%
1
75reviewers would recommend this product Write a Review Ask a Question

Thank you for submitting a review!

Your input is very much appreciated. Share it with your friends so they can enjoy it too!

Filter Reviews:
A
28/07/2022
Anonymous
Australia Australia
I recommend this product
  • How do you rate our services? Awesome

Nano Every

Very productive; nice to have VIN up to 17 Volts

S
08/10/2021
Suny
I recommend this product
  • How do you rate our services? Awesome

Best value for money!

Top quality nano every with 3v and 5v compatibility

A
05/10/2021
Anonymous
Australia Australia
I recommend this product
  • How do you rate our services? Awesome

Arduino Nano Every

Simple on line purchase with local shipping. Product arrived in great shape double boxed and worked exactly as expected. Up and running in minutes.

SL
30/04/2021
Stephen L.
Australia Australia
I recommend this product
  • How do you rate our services? Ok

Typical Nano garbage

No better than any other Arduino Nano devices. Port issues on windows 10, 8, 7 and MACOS. No installing any more drivers!

03/05/2021

Pakronics®

Hi Stephen Thank you for taking time writing. That is very strange to hear. It might be faulty or issue in the library board definition for the new board. Here is the info if you can have a look if you missed any step - https://www.arduino.cc/en/Guide/NANOEvery else do get in touch with us to sort it out. Have a nice day.
