This OV5640 Camera for XIAO ESP32S3 Sense (With Heat Sink) offers a wide active array from 320*240 (QVGA) up to 2592*1944 (QSXGA). It has 8/10-bit RGB RAW output and provides an auto-focusing function.
Feature
- High-quality image sensor customized for Seeed Studio XIAO ESP32S3 Sense
- Wide Resolution: Offer a wide active array from QVGA(320*240) up to QSXGA(2592*1944), boasts excellent resolution, allowing it to deliver high-quality images and videos.
- Multiple Output Formats: This camera offers 8/10-bit RGB RAW output formats.
- Auto-focusing: Provide an auto-focusing function to help users take clear photos and videos more easily
- Strong Environmental Adaptability: Its operating temperature ranges from 30℃ to 70℃, and its storage temperature from 0℃ to 50℃.
Description
This high-quality OV5640 Camera is customized specifically for XIAO ESP32S3 Sense. It offers a wide active array from 320*240 (QVGA) up to 2592*1944 (QSXGA). Moreover, its 8/10-bit RGB RAW output formats excel in applications requiring post-processing, meeting users' demands for raw, unprocessed image data.
The sensor comes with an auto-focusing function to help users take clear photos and videos more easily. The auto-focusing function can automatically adjust the focus distance, ensuring that the captured images and videos are always clear and sharp.
Coupled with its strong environmental adaptability, functioning effectively within a working temperature of 30℃ to 70℃ and a storage temperature range of 0℃ to 50℃, this camera performs excellently under various environmental conditions. It is a powerful and high-performance image sensor with a range of excellent features.
Note
We have provided a heat sink, but please pay attention when using it, beware of burns.
Application
- Security
- Machine Vision
- Autonomous Vehicles
- Household Electronics
Specification
Specifications | Details |
Optical Format | 1/4 inch |
Pixel Size | 1.4 µm x 1.4 µm |
Active Array Size | 2592*1944 |
Output formats | 8-/10-bit RGB RAW output |
Power Supply | core: 1.5V ± 5% (with embedded 1.5V regulator) analog: 2.6 ~ 3.0V (2.8V typical) I/O: 1.8V / 2.8V |
Guaranteed storage temperature | 0℃ to 50℃ |
Guaranteed Operating temperature | 30℃ to 70℃ |
maximum image transfer rate | QSXGA(2592*1944):15fps 1080p:30fps 1280*960:45fps 720p:60fps VGA (640*480):90fps QVGA (320*240):120fps |
Part List
OV5640 Camera for XIAO ESP32S3 Sense (With Heat Sink) | x1 |
ECCN/HTS
| HSCODE | 8525891900 |
| USHSCODE | 8525805050 |
| UPC | |
| EUHSCODE | 8517600000 |
| COO | CHINA |
