7" 1024x600 Touch Display (eDP) for LattePanda Sigma
7" 1024x600 Touch Display (eDP) for LattePanda Sigma

7" 1024x600 Touch Display (eDP) for LattePanda Sigma

Price:
A$140.62   Inc. GST
SKU:
DF-FIT0950
155 units Ships in 7 to 10 days

Excellent Visual Effect

This display utilizes IPS screen technology, providing support for a FULL visual Angle, and boasting a 1024 x 600 resolution with high color saturation for superior picture quality.

Designed For HMI and Portable Projects

Our product design includes multiple optimizations for HMI and portable projects, such as addressing the common issue of dust and complex scenarios. With a fully enclosed design, this display effectively blocks dust and minimizes light reflection. Additionally, the screen edge features double-sided adhesive tape for easy and secure installation.

7 inches 1024x600 Touch Display (eDP) for LattePanda Sigma

Best Compatibility

Unlike other normal HDMI screens, this display uses eDP interface and has the best compatibility with LattePanda Sigma. It allows you to set screen power, brightness, contrast, and other parameters directly in the OS or APIs.

Wiring Diagram of Display and LattePanda Sigma

Wiring Diagram of Display and LattePanda Sigma

Please refer to the instruction sticker at the back of the screen for proper screen connection.



How to Install the 7'' eDP Touch Display for LattePanda Sigma: A Step-by-Step Assembly Guide

Please note: Designed exclusively for the LattePanda Sigma single board computers.

Features:

  • Wide viewing angle for enhanced visibility from different perspectives
  • Multi-touch functionality for intuitive interaction
  • High-quality display with vivid and accurate color reproduction
  • Compact and lightweight design for easy integration into various projects
  • Durable construction with a 6H surface hardness for scratch resistance
  • Quick response time for smooth and responsive touch operations
  • Compatible with the LattePanda Sigma model for seamless integration
  • Versatile applications in human-machine interface (HMI) and portable projects

    • Applications:

  • LattePanda Sigma Single Board Computer

    • Specification:

  • Resolution: 1024 x 600 high resolution
  • Interface: eDP(DP)+I2C(TP)
  • Transmittance85%
  • Surface Hardness 6H
  • Response Time: ≤16ms
  • LCM Luminance: 250 cd/m2
  • Tapping Durability: 200,000,000 times
  • Connector: 30cm FPC Extension Cable
  • Pixel pitch (W×H) 0.1506 × 0.1432 mm
  • Active area (W×H) 154.21 × 85.92 mm
  • Dimensions: 180*110*5 mm / 7.1*4.3*0.2 inches
  • Operating Temperature -20 +70
  • Storage temperature -30 +80
  • Weight(Screen Only): 157.7g

    • Documents:

  • User Manual
  • Data sheet (including mechanical drawing)

    • Product Includes:

  • 7 inches eDP Touch Display x1
  • 30cm eDP cable x1
  • 23cm Touch cable x2
